Flora Rhino 1600-A Single-Pass Corrugated Board Printer
On request
- Single-pass printing at up to 120 m/min
- 600 × 1200 dpi with multi-level greyscale printing
- Feed width 500 – 1600 mm; print width 645 – 1290 mm, 1610 mm optional
- Dual-negative-pressure ink recirculation at high flow
- Automatic dedusting against nozzle blocking from board lint
- Water-based pigment ink, natural drying
Single-pass inkjet printer for corrugated board 1.5 – 15 mm thick, 500 – 1600 mm feed width, water-based pigment ink, up to 120 m/min.
Request a quote- Packaging
- Corrugated board
About this machine
Flora Rhino 1600-A Single-Pass Corrugated Board Printer
The Rhino 1600-A is a single-pass industrial inkjet press for direct digital printing on corrugated board 1.5 – 15 mm thick, on sheets 500 – 1600 mm feed width. It prints CMYK with water-based pigment ink (AQ) that dries naturally, with no curing unit on the line.
Because the heads span the sheet rather than traversing it, output is governed by the resolution chosen. Industrial piezo drop-on-demand heads resolve up to 600 × 1200 dpi. The press runs at 120, 80, 60 and 40 m/min at 600 × 400, 600 × 600, 600 × 800 and 600 × 1200 dpi respectively. Multi-level greyscale printing at 600 × 1200 dpi gives the saturation needed on brown kraft.
The ink system uses dual-negative-pressure recirculation at high flow, which keeps ink moving behind the nozzles instead of standing still between sheets, and ink thermostatting holds drop size steady over a shift. Nozzle cleaning and moistening are automatic. Automatic dedusting is the other mechanism that matters in this application: corrugated board sheds fibre lint, and lint on the nozzle plate is the usual cause of blocked nozzles. Front-edge feed keeps manual handling of the sheet to a minimum, and job changes are made without stopping the line.
Print width is configurable between 645 and 1290 mm as standard, with 1610 mm available as an option, on sheets 400 – 1500 mm long or up to 4000 mm with the optional support. Data reaches the press over optical fibre and the RIP is Photoprint, with the system open to third-party RIP software. Supply is three-phase AC 380 – 400 V at 40 A and 20 kW, with dry compressed air at 6 – 8 bar in a room held at 24 – 28 °C and 50 – 70% relative humidity.
The press suits corrugated packaging plants that need continuous 24/7 output but also take small personalised runs, where changing from one job to the next has to happen without a plate change and without stopping.
Applications
- Direct digital printing on corrugated board 1.5 – 15 mm thick
- Corrugated packaging on sheets up to 1600 mm wide
- Small personalised runs with fast changeover between jobs
- Continuous 24/7 production with consistent print quality
Technical specifications
Performance
- Maximum resolution
- 600 × 1200 dpi
Working area
- Print width
- 645 – 1290 (1610 optional) mm
- Material length
- 400 – 1500 (4000 with the optional support) mm
- Material thickness
- 1.5 – 15 mm
Materials
- Compatible materials
- Corrugated board
Tooling & heads
- Print technology
- Industrial piezo drop-on-demand printheads
Drive & mechanics
- Ink supply
- Dual-negative-pressure recirculation at high flow
- Material handling
- Front-edge feed with automatic dedusting
Software & control
- Data interface
- Optical fibre
- RIP software
- Photoprint, open to third-party RIP
Power & environment
- Power supply
- AC 380 – 400 V, three-phase, 50/60 Hz, 40 A
- Compressed air
- 6 – 8, dry bar
- Operating temperature
- 24 – 28 °C
- Relative humidity
- 50 – 70%
Performance
- Print speed at 600 × 400 / 600 × 600 / 600 × 800 / 600 × 1200 dpi
- 120 / 80 / 60 / 40 m/min
Working area
- Feed width
- 500 – 1600 mm
Tooling & heads
- Ink type and colours
- Water-based pigment (AQ), CMYK
- Ink tank capacity
- 10 l per colour
- Drying / curing
- Natural drying
Power & environment
- Installed power
- 20 kW
Material handling
- Paper feeding
- Pressure-free leading-edge feeder
Dimensions & weight
- Machine dimensions / weight
- 5350 × 4320 × 1950 mm / 7500 kg
- Installation area
- 7350 × 9320 × 3000 mm
- Shipping: printing unit
- 5766 × 2260 × 2420 mm / 6000 kg
- Shipping: feeder
- 3845 × 2100 × 2420 mm / 3000 kg
Specifications, images and descriptions are provided for general guidance and may change without notice. Configurations, performance figures and supplied items can vary by production batch and market. The binding specification, scope of supply and terms are those set out in the written quotation we issue for your order.
Application details
Recommended for
Single-pass inkjet printer for corrugated board 1.5 – 15 mm thick, 500 – 1600 mm feed width, water-based pigment ink, up to 120 m/min.
Series
Flora
Frequently asked questions
How fast does it print?
Speed depends on the resolution you choose, because the heads span the sheet instead of traversing it: 120 m/min at 600 × 400 dpi, 80 m/min at 600 × 600, 60 m/min at 600 × 800 and 40 m/min at 600 × 1200 dpi. Multi-level greyscale at 600 × 1200 dpi gives the saturation needed on brown kraft.
What sheet sizes does it take?
Corrugated board 1.5–15 mm thick with a feed width of 500–1600 mm, and sheets 400–1500 mm long, or up to 4000 mm with the optional support. Print width is configurable from 645 to 1290 mm as standard, with 1610 mm available as an option. Send us your box blanks and we will confirm the print width you need.
Which ink does it use, and does it need a dryer?
It prints CMYK with water-based pigment ink (AQ), which dries naturally, so there is no curing unit on the line. Industrial piezo drop-on-demand heads apply it, and ink thermostatting holds drop size steady over a shift.
How does it avoid blocked nozzles on corrugated board?
Corrugated board sheds fibre lint, and lint on the nozzle plate is the usual cause of blocked nozzles, so the feeder dedusts the board automatically. Dual-negative-pressure recirculation at high flow keeps ink moving behind the nozzles between sheets, and nozzle cleaning and moistening are automatic.
Is it practical for short personalised runs?
Yes. Job changes are made without stopping the line and without a plate change, so small personalised runs fit between longer 24/7 production. A pressure-free leading-edge feeder keeps manual handling of the sheet to a minimum. Data reaches the press over optical fibre; the RIP is Photoprint, open to third-party RIP software.
What does it need on site?
Three-phase AC 380–400 V, 50/60 Hz at 40 A and 20 kW, dry compressed air at 6–8 bar, and a room at 24–28 °C and 50–70% relative humidity. The machine is 5350 × 4320 × 1950 mm and 7500 kg; plan an installation area of 7350 × 9320 × 3000 mm. It ships as a printing unit (5766 × 2260 × 2420 mm, 6000 kg) and a feeder (3845 × 2100 × 2420 mm, 3000 kg).
