Scrap collection drawer
Cut pieces fall into a drawer below the bed for easier clearing and routine housekeeping.
AEON · Nova Super
AEON Nova10 Super
On request
- Dual source: Glass for cutting, RF for engraving
- 1000 × 700 mm bed, 120 kg table load
- RF engraving up to 4,000 mm/s, 1 × 1 mm minimum font
- Glass source 90 W or 100 W
- Chiller 5000 for the Glass source, air-cooled RF
- 100° 8 MP camera positioning and AutoFocus
Dual-source Redline machine: 1000 × 700 mm bed with a Glass tube for cutting and an RF tube engraving at 4,000 mm/s.
Request a quoteWhich bed size and source? Read the guide- Wood & MDF
- Acrylic
- Glass
- Leather
- Paper
- Rubber
- Two-colour ABS
- Signage & advertising
Configurations
| Configuration | Differences | Availability |
|---|---|---|
| Glass 90 W + RF 30 WOn request | Laser source: Glass 90 W · RF source: RF 30 W · Engraving speed (Glass): 1,200 mm/s · Engraving speed (RF): 4,000 mm/s | On request |
| Glass 90 W + RF 60 WOn request | Laser source: Glass 90 W · RF source: RF 60 W · Engraving speed (Glass): 1,200 mm/s · Engraving speed (RF): 4,000 mm/s | On request |
| Glass 100 W + RF 30 WOn request | Laser source: Glass 100 W · RF source: RF 30 W · Engraving speed (Glass): 1,200 mm/s · Engraving speed (RF): 4,000 mm/s | On request |
| Glass 100 W + RF 60 WOn request | Laser source: Glass 100 W · RF source: RF 60 W · Engraving speed (Glass): 1,200 mm/s · Engraving speed (RF): 4,000 mm/s | On request |
About this machine
AEON Nova10 Super
The Nova10 Super carries two sources on one 1000 × 700 mm machine: a Glass tube of 90 W or 100 W for cutting, and an RF tube of 30 W or 60 W that engraves at up to 4,000 mm/s with a 1 × 1 mm minimum font. One job can be engraved with the fine source and cut with the powerful one without moving the workpiece.
Why two sources
A Glass tube gives cutting power at low cost; an RF tube gives a small, stable spot and the speed to fill large engraved areas. Buying both in one frame removes the compromise that a single-source machine forces.
Production details
Chiller 5000 for the Glass source, air-cooled RF, 750 W compressor air assist with a 24 L tank, 500 W automatic integrated exhaust, Smart Panel, 1 G memory, WiFi, AutoFocus and a 100° 8 MP camera.
Extraction
See our fume extraction units for laser and CNC — essential for acrylic, ABS, rubber, leather and wood. Do not cut PVC or other chlorinated plastics on a CO₂ laser: the fume is harmful and corrodes the optics and the mechanics.
AEON Nova10 Super
A large-format dual-source CO₂ machine combining Glass cutting capacity with RF engraving detail, AC servo motion and an 4,000 mm/s maximum RF engraving speed.
NOVA SUPER / LARGE-FORMAT PRODUCTION
Two sources. One production platform.
Use the Glass source for cutting and the RF source for fine, high-speed engraving without moving work between machines.
- 1,000 × 700 mm
- working area
- 200 mm
- Z travel · 120 kg lift capacity
- 4,000 mm/s
- maximum RF engraving speed
SOURCE & MOTION / SUPER
Cut with Glass. Engrave with RF.
The dual-source arrangement combines current catalogue Glass and RF configurations. Glass-side cooling remains water-based; only the RF source is air-cooled.
SMART PANEL / MACHINE STATUS
Operating information at a glance.
Temperature monitoring and machine diagnostics are presented on the control panel, while the illuminated front logo communicates status across the workshop.
OPTICAL PATH / EASIER SERVICE
Designed for practical optical maintenance.
The align-free design simplifies access and replacement for the tube, mirrors and lens, reducing repeated optical-path adjustment during routine service.
MAGNETIC LENS HOLDER
Remove, inspect and refit.
The magnetic holder makes routine lens access straightforward. Alternative 2, 2.5 and 4 inch focal lengths are available for different applications; inclusion depends on the selected configuration.
WORKFLOW / MATERIAL HANDLING
Built around real production work.
Interchangeable work tables
Use the honeycomb or slat table according to the material and process.
Camera positioning
A 100° 8 MP camera supports artwork placement and tracing. AutoFocus and WiFi are included; a LightBurn licence is optional.
Material pass-through
Front and rear openings accommodate longer stock; the active processing area remains 1,000 × 700 mm.
INTEGRATED SUPPORT SYSTEMS
Air, cooling and exhaust within the machine.
The machine integrates a 750 W compressor with a 24 L tank and a 500 W inline exhaust with automatic start-stop. Glass configurations use a built-in Chiller 5000; the RF source is air-cooled.
- 01 · Air assist
- 750 W compressor · 24 L tank
- 02 · Inline exhaust
- 500 W · automatic start-stop
- 03 · Cooling
- Chiller 5000 for Glass · air-cooled RF
PLAN YOUR WORKSPACE
Extraction and material safety.
CO₂ processing produces fumes. Use suitable extraction and process only exact material grades explicitly approved for laser use. PVC must not be laser processed; extraction does not make an unsuitable material safe.
Plastics, rubber and composites require verification against the manufacturer’s safety documentation. This machine is not presented for bare-metal or glass cutting.
Explore fume extraction units for laser and CNC →Technical specifications
Work area
- Work area
- 1000 × 700 mm
- Z travel
- 200 mm
- Max. Z load
- 120 kg
Laser source
- Glass laser tube
- 90 W / 100 W
- RF laser tube
- 30 W / 60 W
Speed & motion
- Engraving speed (Glass)
- 1,200 mm/s
- Engraving speed (RF)
- 4,000 mm/s
- Acceleration (Glass)
- 5G
- Acceleration (RF)
- 8G
- Motors (Glass)
- DC stepper
- Motors (RF)
- AC servo
- Minimum font (RF)
- 1.0 × 1.0 mm
- Positioning accuracy
- ≤ 0.1 mm
Cooling & air
- Chiller
- Integrated Chiller 5000 (Glass source)
- RF source cooling
- Air-cooled
- Air assist
- 750 W compressor / 24 L tank
- Exhaust
- 500 W, integrated, automatic
Table & optics
- Table
- Honeycomb + slat
- AutoFocus
- Yes
- Camera
- 100° · 8 MP (3840 × 2160)
Control & connectivity
- Smart Panel
- Yes
- Internal memory
- 1 G
- WiFi
- Yes
Dimensions & weight
- Packed dimensions
- 1500 × 1210 × 1125 mm
- Net weight
- 415 kg
- Gross weight
- 532 kg
Software
- Operating software
- RDWorks / LightBurn (optional)
- Design software
- CorelDraw / Illustrator / AutoCAD
Specifications, images and descriptions are provided for general guidance and may change without notice. Configurations, performance figures and supplied items can vary by production batch and market. The binding specification, scope of supply and terms are those set out in the written quotation we issue for your order.
Application details
Recommended for
Intensive production needing both ultra-fast engraving and strong cutting.
Series
Nova Super
Frequently asked questions
Why would we need two laser sources?
Because one job can then be engraved with the fine source and cut with the powerful one without moving the workpiece. The Glass tube, 90 W or 100 W, gives cutting power; the RF tube, 30 W or 60 W, gives a small, stable spot and the speed to fill large engraved areas. Having both in one frame removes the compromise a single-source machine forces.
Which source combination should we choose?
There are four: Glass 90 W or 100 W, each with RF 30 W or 60 W. Engraving speeds are the same on all four, 1,200 mm/s for Glass and 4,000 mm/s for RF, so the choice is tube power. Pick the Glass power for the material you cut and the RF power for your engraving work; send us both and we will recommend a pairing.
How fine and fast is the engraving?
The RF source engraves at up to 4,000 mm/s with a 1 × 1 mm minimum font, which suits fine lettering and large filled areas alike. The Glass source engraves at 1,200 mm/s if you prefer to use it.
How large are the bed and the table load?
The bed is 1000 × 700 mm with 200 mm of Z travel and a 120 kg table load. Honeycomb and slat tables are available for engraving and cutting, and AutoFocus sets the height for each thickness.
How are the two sources cooled?
The Glass tube is cooled by an integrated Chiller 5000; the RF tube is air-cooled. Air assist comes from a 750 W compressor with a 24 L tank, and the 500 W integrated exhaust runs automatically. For PVC, ABS, polycarbonate, rubber and composites, separate fume extraction is mandatory.
How are jobs positioned and controlled?
A 100° 8 MP camera (3840 × 2160) and AutoFocus handle placement and height, with ≤ 0.1 mm positioning accuracy. Smart Panel, 1 G of memory and WiFi are on the machine. RDWorks is the operating software, LightBurn optional, with designs from CorelDraw, Illustrator or AutoCAD.
What do we need on site?
A level floor for a 415 kg machine. It ships at 1500 × 1210 × 1125 mm and 532 kg gross, so plan for a forklift or a pallet truck at delivery. We confirm the electrical supply with your quote and can recommend extraction for your materials.
